Pr inted in black on clear
for use in conjunction with
coloured pipe ID tape.
Supplied in packs of 25 size
105mm x 55mm
The tapes shown here are
available in 100mm wide rolls.
The text is repeated throughout
the roll and aids identification of
pipe contents.
ID15C
Clear
ID15W
White
50mm x 33m
ID18
ID19
ID110
min.order 4 packs
WATER
HOT WATER
(ADD YOUR TEXT)
WATER
HOT WATER
(ADD YOUR TEXT)
ID105
ID106
ID107
ID108
ID109
INSTRUMENT AIR
FUEL OILS
OXYGEN
ELECTRICITY
ACID
INSTRUMENT AIR
FUEL OILS
OXYGEN
ELECTRICITY
ACID
ID100
ID101
ID102
ID103
ID104
DRINKING WATER
TOWNS WATER
STEAM
FIRE MAIN
COMPRESSED AIR
DRINKING WATER
TOWNS WATER
STEAM
FIRE MAIN
COMPRESSED AIR
Shown here are the basi c
ident i f icat ion colours these
should be placed either side
of the centre band and are
available in 50mm, 100mm &
150mm wide by 33m long.
ID1
Water
Green (12D45)
ID2
Steam
Silver Grey (10A03)
ID3
Mineral oils
Brown (06C39)
ID4
Gases (except air)
Yellow Ochre (08C35)
ID5
Acids & Alkalies
Violet (22C37)
ID6
Air
Light Blue (20E51)
ID7
Electrical services
and vent ducts
Orange (06E51)
ID8
Other fluids
Black (00E53)
Shown here are the centre band
colours all available in 50mm,
100mm & 150mm wide by 33m
long.
ID62
White
ID63
Crimson
ID64
Blue (18E51)
ID65
Golden Brown (06D45)
ID9
Fire fighting
Red (04E53)
ID13
Fresh water
Aux. Blue (18E53)
ID60
Warning
Yellow (08E51)
ID61
Warning/Danger
Yellow/Black (ID10)
ID66
Salmon Pink (04C33)
ID67
Sea Green (16C37)
ID11
Primrose (10E53)
ID68
Emerald (14E53)
Pipes should be marked
with two bands of basic i.d.
colour 150mm and a centre
band of 100mm where the
exact nature of the content
needs to be recognised.
To fur ther enhance your
scheme the content can be
stated with a black on clear
name label and the direction
of flow indicated with flow
arrows, while symbols should
be added for easy hazard
identification.
British Standard Pipe Identification
Clear Texted Pipe Labels
Basic Identification Colours
Safety Reference Colours
